Kursk - Messerschmidt Bf110
| Messerschmidt Bf110C-4 | Fighter | ||||||||
| Year - 1939 | Crew - 2-3 | Engines - 2 821kW Daimler-Benz DB601-A1 | |||||||
| Span (m) | Length (m) | Height (m) | Wing Area (m2) | ||||||
| 16.27 | 12.65 | 3.5 | 38.4 | ||||||
| Weight (Kg) | Max Weight (Kg) | Speed (Km/h) | Ceiling (m) | Range (Km) | |||||
| 5,200 | 6,750 | 560 | 10,000 | 1,120 | |||||
| Armaments: | |||||||||
| 2 20mm Cannon; 5 7.92mm MG | |||||||||
| The Bf 110 was a heavy twin-engine fighter, designed for fighter-bomber, bomber-interceptor, and escort fighter missions. Its use as escort fighter during the Battle of Britain was disastrous, because the Bf 110 was too vulnerable in a dogfight with single-engine fighters. Hence the Bf 110 acquired a poor reputation. But it had a good record as interceptor, fighter-bomber and especially as night-fighter. 6100 built. | |||||||||
Images:
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
